POWER

700W RMS 4 ohm (head), 600W RMS 4 ohm (speaker)

DIMENSIONS

Dimensions: 62 x 51 x 30 cm

Weight: 20,5 Kg

PLUS

- VU meter led
- 9 Volt Output pedal effects
- Switch fan on/off noiseless
- Subsonic filter for woofer protection
- Color: black (other colours available on request)
- Panel+logo: brushed aluminium with possibility of colours customization

FRONT PANEL

- Input
- V meter dot bar
- -10 db
- Aux In
- Gain
- Mid Eq
- Bass
- Mid Frequency 400-800 hz
- High
- Sub Filter
- Volume DI / headphone
- Master
- Mute
- Led mute
- Out headphone

REAR PANEL

- Input 230-115v (auto selectable)
- 9 Volt
- Tuner Out
- Send/Return
- Pre/Post DI
- DI Output
- Speakon/Jack Outputs

BASS REFLEX

on front

TWEETER

1" with Lpad regulator

FREQUENCY RESPONSE

35Hz to 22 kHz

SENSITIVITY

98 dB SPL
